CH742 - 25 hp 747cc

Product 3/12

Kohler Engine CH742-3101 25 hp Command Pro 747cc 1 7/16 CS

Click to enlarge

Kohler Engine CH742-3101 25 hp Command Pro 747cc 1 7/16 CS

Name: Kohler Engine CH742-3101 25 hp Command Pro 747cc 1 7/16 CS
Brand: Kohler
Price: 3299.99 USD
Availability: InStock

$3299.99$3653.00
Save: 10% off

Add Qty:

Description

25 hp, Kohler Command Pro Engine, 747cc, 1 7/16 Crankshaft, CH742-3101, Free Shipping No Tax

Replaces Old Kohler Engine Spec # CH740-3001, CH740-3100

Standard Features:

Overhead Valve Design
Hydraulic Valve Lifters
Heavy Duty Canister Air Cleaner System
Fixed Grass Screen Guard
Cast-Iron Cylinder Liners
PTO Sleeve Bearing (Side Load)
Electronic Ignition
High Efficiency Grass Screen and Fan
Closed Breather System
Stellite Exhaust Valves
Full Pressure Lubrication
Large Capacity In-Line Fuel Filter
Large Capacity Oil Filter
Dual Oil Drain
Oil Sentry (Switch Installed and Wired but Unconnected)
Engine-Mounted Oil Cooler, Radiator Style
Variable Speed Governor
High Performance Twin Barrel Carburetor
Fuel Shutdown Solenoid
Smart-Choke Carburetor
Mechanical Fuel Pump
High Performance Spark Plugs
12 Volt Solenoid Shift Starter
20 Amp Alternator, Regulated
Crankshaft-1.437 inch (36 mm) Diameter x 4.46 inch (113 mm) PTO Length, 0.375 inch (9.5 mm) Keyway, Drilled and Tapped 1.5 inch (38 mm) Deep, 5/8-18 UNF
PTO Face-5.625 inch (143 mm) Diameter, (4 Holes) 3/8-16 x 0.67inch (17 mm) Deep, 7.75 inch (197 mm) Diameter, (4 Holes) 7/16-14 x 0.83 inch (21 mm) Deep
7 inch (178 mm) Diameter Pilot
Engine Mounted Controls- Key Switch, Throttle and Choke Controls

See Exhaust Systems
2478610S PTO Canister Muffler Kit-Center Outlet
2478611S PTO Canister Muffler Kit-Filter Side Outlet
2478612S PTO Canister Muffler Kit-Starter Side Outlet
2478619S Side Mount Muffler Kit-Starter Side
2478620S Side Mount Muffler Kit-Filter Side
2478621S Raised Body PTO Canister Kit-Filter Side Outlet
2478622S Raised Body PTO Canister Kit-Starter Side Outlet

Specs

Model: PACH742-3101
UPC: 885612192288
Shipping Weight: 125lbs
Manufactured by: Kohler
