Kohler Engine ECV749-3064 26.5 hp Command Pro Efi 747cc Exmark

Name: Kohler Engine ECV749-3064 26.5 hp Command Pro Efi 747cc Exmark
Brand: Kohler
Price: 2899.95 USD
Availability: InStock

$2899.95$3110.54
Save: 7% off

Add Qty:

26.5 hp Kohler ECV749-3064 Electronic Fuel Injected (EFI) Command Pro Engine, 747cc, Exmark

Replaces Old Kohler Spec# ECV749-3011, ECV749-3014 will need this adaptor 2517622S. (see related product below)

Crankshaft 24014207 1.125 in (1 1/8) (28.56 mm) Diameter x 4.30 in (109 mm) PTO Length, 0.25 in (6 mm) Keyway, Drilled and Tapped 1.5 in (38 mm) Deep, 7/16-20 UNF
PTO Face-10 in (254 mm) Diameter, 4 Through Holes, 0.36 in (9 mm) Diameter
3yr Warranty
Overhead Valve Design
Hydraulic Valve Lifters
Cast-Iron Cylinder Liners
PTO Sleeve Bearing (Side Load)
Electronic Ignition
Heavy Duty Canister Air Cleaner System 2401846S
High Efficiency Grass Screen and Fan
Closed Breather System
Stellite Exhaust Valves
Full Pressure Lubrication
In-Line Fuel Filter
Easy Access Valve Cover Oil Fill-Yellow
Oil Level Dipstick-Yellow
Large Capacity Oil Filter, Dual Oil Drain
Oil Sentry
Variable Speed Governor
Pulse Fuel Pump
High Performance Spark Plugs
12 Volt Solenoid Shift Starter
Special Chopper Grass Screen & Fixed Guard
20 Amp Alternator, Regulated
Wiring harness 24176269S
3/16" Evaporative emissions connection
Includes Oxygen Sensor For Exhaust

Model	Command PRO EFI ECV749
HP (kW) 1	26.5(19.8)
Displacement (cc)	45 (747)
Bore in (mm)	3.3 (83)
Stroke in (mm)	2.7 (69)
Gross Torque ft lbs (Nm) 1	40.9 (55.5)
Compression Ratio	9.1:1
Dry Weight lbs (kg)	108 (49)
Oil Capacity US qts (L)	2(1.9)
Lubrication	Full pressure w/full-flow filter
Dimensions LxWxH (in)*	21.3x18.5x17.6
Backpressure Limit 2	50
Certified Power HP (kW) 3	25.5(19)
Certified RPM	3600
Emissions Compliance	CARB Phase III
	EU Stage V
	EPA Phase III
Engine Type	Commercial
